Cat6 Keystone Jack

Products > Structured Cabling > Copper Cables Cat6

CAT6 Shielded Keystone Jack CAT6 V-Max Keystone Jacks CAT6A Shielded Keystone Jack Cat6a V-Max Keystone

CAT6 Shielded Keystone Jack Vertical Cable CAT6 Shielded Jacks deliver protection from EMI. These work flawlessly with CAT6 shielded cables in indoor applications. Both, A and B, wiring codes are printed on the IDCs. Physical Specifications • Dimension (mm) 19.35H x 21W x 46.83D Housing Material • Housing & Cap Polycarbonate Contact Material • 110/Krone Type Contacts 100μ Inch nickel plated over phosphor bronze • IDC Operating Life Minimum 250 re-terminations • Jack Contact Phosphor bronze, 50μ inch gold plating over nickel • Jack Operating Life Minimum 750 insertions • Compatibility 23 to 26 AWG (solid) • Shielded Cover 50~60μ inch nickel plated over phosphor bronze.	Electrical • Dielectric Strength 1000V RMS for 1min • Insulation resistance 10mΩ min • Contact Resistance 2mΩ per contact • Temperature Range -10°C to 60°C max • Humidity 10%~65% AN Features: • 360deg. Shielding Structure to prevent EMI • 110/Krone Type Contacts (Terminal Block) • Color Coded for 568A and 568B • EIA/TIA 568A/B standards • ANSI/TIA-568-C.2 , ISO/IEC11801, EN50173-1 • Thermoplastic ABS Housing • UL Listed, ETL Listed, RoHS Compliant • 50 per bag

CAT6 V-Max Keystone Jacks CAT6 V-Max Jacks are also compatible with the Vertical Cable I-Punch tool that saves installation time. These sturdy jacks hold well, and can be snapped in and out of multiple times. Bla Physical Specifications: • Dimension (mm) 19.86H x 17W x 31D Housing Materials • Housing UL 94 V-0 self extinguished plastic • DC Housing UL 94 V-0 self extinguished plastic Contact Material • IDC 110 Contacts Phosphor bronze, nickel plated • Nose Contacts 50μ gold plating over nickel • Operating Life Minimum 750 insertions • Compatibility 22 to 26 AWG Solid • PBC FR-4 1.6mm double sided • Cap UL 94V-0 rated	Applications: • 10Base-T Ethernet • 155/622 Mbps ATM • 4/16 Mbps Token Ring • 100VG-Any LAN Features: • Available in various colors for easy Identification • 8 Conductor solder-plated phosphor bronze 110-IDC contacts • Narrow connectors allow high port density in small areas • EIA/TIA 568A/B standard • ISO/IEC11801 2nd edition EN50173 2nd edition • ANSI/TIA-568-C.2, FCC, 3P • UL94V-0 Thermoplastic ABS Housing • UL Listed, ETL Listed, RoHS Compliant • 50 per bag

CAT6A Shielded Keystone Jack Vertical Cable CAT6A Shielded Jacks offer the highest level of performance for modular connections. These work with CAT6A shielded cable, as well as lower category and unshielded cable. A and B wiring codes are stamped on the IDCs. The jacks have tough housings that snap in and out of keystone ports. Physical Specifications • Dimension (mm) 19H x 21W x 38.1D Housing Material • Housing & Cap Polycarbonate Contact Material • 110/Krone Type 100μ Inch nickel plated over phosphor bronze • IDC Operating Life Minimum 250 re-terminations • Jack Contact Phosphor bronze, 50μ inch gold plating over nickel • Jack Operating Life Minimum 750 insertions • Compatibility 23 to 26 AWG (solid) • Shielded Cover 50~60μ inch nickel plated over phosphor bronze	Electrical • Dielectric Strength 1000V RMS for 1min • Insulation resistance 10mΩ min • Contact Resistance 2mΩ per contact • Humidity 10%~65% AN Features: • 110/Krone Type IDC (Terminal Block • 360o Shielding Structure to prevent EMI • TIA/EIA-568C.2, IEEE802.3an • ISO/IEC11801, EN50173-1 Class EA Specification • Comply with CISPR/FCC Class A • 3P Verified for 10G Cat6A • Flame retardant rating: UL 94V-0 • ETL Listed, RoHS Compliant • 50 per bag

CAT6A V-Max Keystone Jacks Vertical Cable CAT6A Jacks are compatible with all our CAT6A cables. Additionally, all our CAT6A Jacks are compatible with the I-Punch tool. Physical Specifications • Dimension (mm) 19.86H x 17W x 31D Housing Materials • Housing High-Impact Thermoplastic (UL 94 V-0) • DC Housing Polycarbonate (UL 94 V-0) Contact Material • IDC 110 Contacts Solder-Plated Phosphor Bronze • Nose Contacts 50μ of gold plating over nickel plating • Operating Life Minimum 750 insertions • Compatibility 22 to 26 AWG Solid • PBC FR-4 1.6mm thickness • Cap High-Impact Thermoplastic (UL 94 V-0)	Applications: • 10GBase-T Ethernet • 1000Base-Tx Gigabit Ethernet • 100Base-Tx Fast Ethernet Features: • 8 Conductor solder-plated phosphor bronze 110-IDC contacts • Improved PCB Design and IDC Geometry provide superior performance • TIA/EIA 568C.2, IEEE802.3an for 10GBase-T Requirements • ISO 11801, EN 50173-1 Class EA Specification • UL94V-0 Thermoplastic ABS Housing • ETL Listed, RoHS Compliant • 50 per bag
